Building Multi-Step Workflows

Ferni Dev Team January 8, 2026

15 min read

The Ferni Workflow Engine lets you build multi-step automations that voice agents can execute. From simple sequences to complex DAGs with parallel branches, workflows bring your integrations to life.

What is a Workflow?

A workflow is a directed graph of nodes connected by edges. Each node performs an action:

MCP Call - Execute a tool from an MCP server
Webhook - Call an external HTTP endpoint
LLM Prompt - Generate text with the language model
Condition - Branch based on an expression
Parallel - Execute multiple branches simultaneously
Wait - Pause for time or an event

Basic Workflow Structure

{
  "name": "Customer Lookup",
  "trigger": {
    "type": "voice_command",
    "config": { "command": "look up customer" }
  },
  "nodes": [
    { "id": "start", "type": "start" },
    { "id": "lookup", "type": "mcp_call", "config": {...} },
    { "id": "respond", "type": "llm_prompt", "config": {...} },
    { "id": "end", "type": "end" }
  ],
  "edges": [
    { "sourceId": "start", "targetId": "lookup" },
    { "sourceId": "lookup", "targetId": "respond" },
    { "sourceId": "respond", "targetId": "end" }
  ],
  "entryNodeId": "start"
}

Creating Your First Workflow

Let's build a "Daily Standup" workflow that:

Fetches today's calendar events
Checks if there are meetings
Summarizes them for the user

Step 1: Define the Trigger

{
  "trigger": {
    "type": "voice_command",
    "config": {
      "command": "start standup"
    }
  }
}

Trigger types include:

voice_command - Triggered by speech
schedule - Cron-based scheduling
event - Triggered by webhook events
api - Triggered via API call

Step 2: Add Nodes

{
  "nodes": [
    {
      "id": "start",
      "type": "start",
      "name": "Start"
    },
    {
      "id": "fetch-calendar",
      "type": "mcp_call",
      "name": "Fetch Calendar",
      "config": {
        "serverId": "mcp_google_calendar",
        "toolName": "calendar.getEvents",
        "arguments": {
          "date": "{{today}}",
          "maxResults": 10
        }
      }
    },
    {
      "id": "check-meetings",
      "type": "condition",
      "name": "Has Meetings?",
      "config": {
        "expression": "fetch-calendar.result.events.length > 0"
      }
    },
    {
      "id": "summarize",
      "type": "llm_prompt",
      "name": "Summarize Meetings",
      "config": {
        "prompt": "Summarize these meetings for a quick standup briefing:\n\n{{fetch-calendar.result.events | json}}",
        "outputVariable": "summary"
      }
    },
    {
      "id": "no-meetings",
      "type": "set_variable",
      "name": "No Meetings Message",
      "config": {
        "variable": "summary",
        "value": "No meetings scheduled for today. Your calendar is clear!"
      }
    },
    {
      "id": "speak",
      "type": "speak",
      "name": "Tell User",
      "config": {
        "text": "{{summary}}"
      }
    },
    {
      "id": "end",
      "type": "end",
      "name": "End"
    }
  ]
}

Step 3: Connect with Edges

{
  "edges": [
    { "id": "e1", "sourceId": "start", "targetId": "fetch-calendar" },
    { "id": "e2", "sourceId": "fetch-calendar", "targetId": "check-meetings" },
    { "id": "e3", "sourceId": "check-meetings", "targetId": "summarize", "condition": "true" },
    { "id": "e4", "sourceId": "check-meetings", "targetId": "no-meetings", "condition": "false" },
    { "id": "e5", "sourceId": "summarize", "targetId": "speak" },
    { "id": "e6", "sourceId": "no-meetings", "targetId": "speak" },
    { "id": "e7", "sourceId": "speak", "targetId": "end" }
  ]
}

Step 4: Create via API

curl -X POST https://api.ferni.ai/api/v2/developers/workflows \
  -H "Authorization: Bearer pk_live_xxx" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "Daily Standup",
    "description": "Summarizes today calendar for morning standup",
    "trigger": {
      "type": "voice_command",
      "config": { "command": "start standup" }
    },
    "nodes": [...],
    "edges": [...],
    "entryNodeId": "start",
    "enabled": true
  }'

Node Types Reference

MCP Call

Execute a tool from a registered MCP server:

{
  "id": "lookup",
  "type": "mcp_call",
  "config": {
    "serverId": "mcp_crm",
    "toolName": "lookup_customer",
    "arguments": {
      "query": "{{input.customerName}}"
    }
  }
}

Results are available as {nodeId}.result.

Webhook

Call an external HTTP endpoint:

{
  "id": "notify-slack",
  "type": "webhook",
  "config": {
    "url": "https://hooks.slack.com/services/xxx",
    "method": "POST",
    "headers": {
      "Content-Type": "application/json"
    },
    "body": {
      "text": "Workflow completed: {{workflowName}}"
    }
  }
}

LLM Prompt

Generate text using the language model:

{
  "id": "summarize",
  "type": "llm_prompt",
  "config": {
    "prompt": "Summarize this customer interaction:\n\n{{transcript}}",
    "model": "gemini-2.0-flash",
    "outputVariable": "summary"
  }
}

Condition

Branch based on an expression:

{
  "id": "check-priority",
  "type": "condition",
  "config": {
    "expression": "ticket.priority === 'high'"
  }
}

Connect with conditional edges:

{ "sourceId": "check-priority", "targetId": "urgent-flow", "condition": "true" },
{ "sourceId": "check-priority", "targetId": "normal-flow", "condition": "false" }

Parallel

Execute multiple branches simultaneously:

{
  "id": "parallel-fetch",
  "type": "parallel",
  "config": {
    "branches": [
      { "entryNodeId": "fetch-calendar" },
      { "entryNodeId": "fetch-tasks" },
      { "entryNodeId": "fetch-emails" }
    ]
  }
}

All branches must complete before continuing.

Wait

Pause execution:

{
  "id": "wait-approval",
  "type": "wait",
  "config": {
    "duration": 60000,          // Wait 60 seconds
    "event": "approval.received" // Or wait for event
  }
}

Set Variable

Store a value for later use:

{
  "id": "set-status",
  "type": "set_variable",
  "config": {
    "variable": "ticketStatus",
    "value": "resolved"
  }
}

Activity

Log a custom activity:

{
  "id": "log-completion",
  "type": "activity",
  "config": {
    "type": "workflow_completed",
    "name": "Daily Standup",
    "data": {
      "meetingCount": "{{fetch-calendar.result.events.length}}"
    }
  }
}

Variable Interpolation

Use {{expression}} syntax to reference:

Input variables: {{input.customerName}}
Node results: {{nodeId.result}}
Workflow variables: {{variableName}}
Built-ins: {{today}}, {{now}}, {{userId}}

Filters

Apply transformations with pipe syntax:

{{data | json}}           // JSON stringify
{{text | uppercase}}      // Uppercase
{{list | first}}          // First item
{{number | round}}        // Round number
{{date | format('MMM d')}} // Format date

Error Handling

Per-Node Error Handling

{
  "id": "risky-operation",
  "type": "webhook",
  "config": {...},
  "onError": {
    "type": "goto",
    "targetNodeId": "error-handler"
  }
}

Retry Policy

{
  "id": "flaky-api",
  "type": "webhook",
  "config": {...},
  "retry": {
    "maxAttempts": 3,
    "backoffMs": 1000,
    "backoffMultiplier": 2
  }
}

Global Error Handler

{
  "errorHandler": {
    "nodeId": "global-error-handler"
  }
}

Testing Workflows

Test via API

curl -X POST https://api.ferni.ai/api/v2/developers/workflows/wf_xxx/test \
  -H "Authorization: Bearer pk_live_xxx" \
  -H "Content-Type: application/json" \
  -d '{
    "input": {
      "customerName": "Acme Corp"
    }
  }'

Dry Run

Execute without side effects:

curl -X POST https://api.ferni.ai/api/v2/developers/workflows/wf_xxx/test \
  -H "Authorization: Bearer pk_live_xxx" \
  -d '{
    "dryRun": true,
    "input": {...}
  }'

Execution History

List Executions

curl https://api.ferni.ai/api/v2/developers/workflows/wf_xxx/executions \
  -H "Authorization: Bearer pk_live_xxx"

Execution Details

curl https://api.ferni.ai/api/v2/developers/workflows/wf_xxx/executions/exec_yyy \
  -H "Authorization: Bearer pk_live_xxx"

{
  "success": true,
  "data": {
    "id": "exec_yyy",
    "workflowId": "wf_xxx",
    "status": "completed",
    "triggeredBy": "voice",
    "startedAt": "2026-01-11T10:00:00Z",
    "completedAt": "2026-01-11T10:00:05Z",
    "duration": 5000,
    "nodeResults": {
      "fetch-calendar": {
        "status": "completed",
        "duration": 1200,
        "result": {...}
      },
      "summarize": {
        "status": "completed",
        "duration": 2100,
        "result": {...}
      }
    }
  }
}

Real-World Examples

Customer Onboarding Flow

{
  "name": "Customer Onboarding",
  "trigger": { "type": "voice_command", "config": { "command": "onboard new customer" } },
  "nodes": [
    { "id": "start", "type": "start" },
    { "id": "get-info", "type": "llm_prompt", "config": {
      "prompt": "Extract customer name, email, and company from: {{input.transcript}}"
    }},
    { "id": "create-crm", "type": "mcp_call", "config": {
      "serverId": "mcp_crm",
      "toolName": "create_customer",
      "arguments": { "data": "{{get-info.result}}" }
    }},
    { "id": "send-welcome", "type": "webhook", "config": {
      "url": "https://api.sendgrid.com/v3/mail/send",
      "method": "POST",
      "body": { "to": "{{get-info.result.email}}", "template": "welcome" }
    }},
    { "id": "confirm", "type": "speak", "config": {
      "text": "I've added {{get-info.result.name}} to your CRM and sent them a welcome email."
    }},
    { "id": "end", "type": "end" }
  ],
  "edges": [
    { "sourceId": "start", "targetId": "get-info" },
    { "sourceId": "get-info", "targetId": "create-crm" },
    { "sourceId": "create-crm", "targetId": "send-welcome" },
    { "sourceId": "send-welcome", "targetId": "confirm" },
    { "sourceId": "confirm", "targetId": "end" }
  ]
}

Scheduled Report

{
  "name": "Daily Sales Report",
  "trigger": {
    "type": "schedule",
    "config": { "cron": "0 9 * * 1-5" }
  },
  "nodes": [
    { "id": "start", "type": "start" },
    { "id": "fetch-sales", "type": "mcp_call", "config": {
      "serverId": "mcp_analytics",
      "toolName": "get_sales_summary",
      "arguments": { "period": "yesterday" }
    }},
    { "id": "generate-report", "type": "llm_prompt", "config": {
      "prompt": "Generate a brief sales report from: {{fetch-sales.result}}"
    }},
    { "id": "send-slack", "type": "webhook", "config": {
      "url": "{{secrets.SLACK_WEBHOOK}}",
      "body": { "text": "📊 *Daily Sales Report*\n{{generate-report.result}}" }
    }},
    { "id": "end", "type": "end" }
  ]
}

Best Practices

Keep workflows focused - One workflow, one purpose
Use meaningful node names - Makes debugging easier
Handle errors gracefully - Add error handlers for critical paths
Test with dry runs - Validate before production
Monitor executions - Check logs for failures
Version your workflows - Track changes over time
